5106-IK + EAM-S

Low Voltage LED Sign Light on an Extended Arm Mount

The 5106-IK + EAM-S is a Sign Light fixture integrating factory-fitted LEDs for high-performance illumination. Encased in a robust A360 die-cast aluminum body, the fixture is designed for efficiency and durability. The 5106 delivers up to 400 lumens with wattages from 2W to 4W and offers color temperature choices from 3000°K to 5000°K. Its door is designed to shed water from the lens surface, and a durable polyester powder coat finish is available in 18 standard colors. The fixture's fully adjustable Infinity Knuckle is mounted on an Extended Arm Mount, extending the fixture off a surface for a variety of lighting applications.
Specification Sheet

Resources

CCT

  • 3000K
  • 4000K
  • 5000K

CRI

  • 80

Color / Finish

  • Architectural Brick
  • Architectural Bronze
  • Black
  • Dark Bronze
  • Glossy Gray
  • Granite
  • Graphite Metallic
  • Hunter Green
  • Light Bronze
  • Mocha
  • Olde Finish
  • Pewter
  • Rust
  • Special Bronze
  • Verde
  • Weathered Bronze
  • Weathered Iron
  • White

Lamp Source

  • LED

Listings

  • cULus

Lumens

  • 200
  • 400

Materials

  • Aluminum

Mounting

  • EAM

Ratings & Compliance

  • Build America Buy America (BABA)
  • Buy American Act (BAA)

Static LED Color

  • White

Voltage

  • 12 V

Watts

  • 2
  • 3
  • 4
