3105-IK + EAM-D
Double Low Voltage LED Sign Light on an Extended Arm Mount
The 3105-IK + EAM-D is a dual Sign Light fixture with integrated high-density array (HDA) LED. It features high-performance reflector optics, integral drivers, and a durable A360 die-cast aluminum body. The 3105 delivers up to 750 lumens, with wattages ranging from 4.5W to 13W and color temperatures from 2700°K to 5000°K. Its door is designed to shed water from the lens surface, and a durable polyester powder coat finish is available in 18 standard colors. The fixtures' fully adjustable Infinity Knuckles are mounted on an Extended Arm Mount, extending the fixtures off a surface for a variety of lighting applications.
Resources
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
CRI
- 80
Color / Finish
- Architectural Brick
- Architectural Bronze
- Black
- Dark Bronze
- Glossy Gray
- Granite
- Graphite Metallic
- Hunter Green
- Light Bronze
- Mocha
- Olde Finish
- Pewter
- Rust
- Special Bronze
- Verde
- Weathered Bronze
- Weathered Iron
- White
Lamp Source
- LED
Listings
- cULus
Lumens
- 135
- 214
- 269
- 321
- 332
- 364
- 487
- 542
- 566
- 687
- 711
- 738
Materials
- Aluminum
Mounting
- EAM
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
Static LED Color
- White
Voltage
- 12 V
Watts
- 4.5
- 9.5
- 13
